The MAGIC DC7 XIP RM offers the same functions as the MAGIC DC7 XIP Audio Codec, but is realised as 19″ unit with an integrated power supply.


The MAGIC DC7 XIP RM Audio Codec provides a LAN, an ISDN BRI and an X.21 interface. In the ISDN mode as well as in the IP mode, two Audio Codecs with the G.711 and G.722 coding algorithms are available. MAGIC DC7 XIP RM offers analogue and (optional) digital Audios interfaces.

From software version 3.000 upwards MAGIC AC1 XIP RM provides the so-called ISDN/SIP Auto Mode. Using this mode the system detects automatically via which line interface (ISDN or LAN) a call is received.


The system can be operated via the front keypad and display. The menu is similar to standard mobile phone and very user-friendly. Another option for control and configuration is the MAGIC DC7/AC1 Windows PC Software or the MAGIC DC7/AC1 LAN Windows PC Software. The LAN software allows simultaneous monitoring, configuration and control of up to 10 Audio Codecs within a network. Individual systems can be dynamically selected for Audio transmissions. System errors are automatically reported and filed.
Both Software Versions are included in the delivery.
